Products Description
- Fuel-efficient turbocharged engine with strong power and high torque reserve for heavy-duty performance.
- Hydraulic fork positioner for easy operation and reduced operator fatigue.
- The reinforced mast with roller bearings ensures stable lifting and long service life.
- Full-hydraulic steering system with transverse oil cylinder bridge for flexible and reliable control.
- Large-capacity cooling system with advanced heat dissipation technology for continuous operation.
- Durable electrical system with waterproof wiring harness and multi-fuse protection for enhanced safety.
Products Description
Reliable Machines, Secure Logistics
Products service
|
Model |
FD160 |
||
|
Features |
Rated Load |
Kg |
16000 |
|
Load Center |
mm |
900 |
|
|
Wheelbase |
mm |
3800 |
|
|
Weight |
Weight |
kg |
24000 |
|
Chassis |
Tire Specs: Front |
12.00-24 |
|
|
Tire Specs: Rear |
12.00-20 |
||
|
Tires Qt y, front/rear(X-dreve wheels) |
4/2 |
||
|
Wheel tread: Front |
mm |
2070 |
|
|
Wheel tread: Rear |
mm |
2130 |
|
|
Dimensions |
Mast/carriage tilt angle(front/rear) |
Degree(°) |
6/12 |
|
Mast height(fork lowering) |
mm |
3520 |
|
|
Mast lifting height |
mm |
3500 |
|
|
Max. height |
mm |
5240 |
|
|
height to head guard(height to cab) |
mm |
3210 |
|
|
Overall height(with forks) |
mm |
7530 |
|
|
Fork front vertical surface to the rear end of the vehicle |
mm |
5730 |
|
|
Overall width |
mm |
2750 |
|
|
Fork dimension |
mm |
1800*200*100 |
|
|
Fork carriage width |
mm |
2700 |
|
|
Mast min ground(with load) |
mm |
300 |
|
|
Wheelbase center min ground(with load) |
mm |
350 |
|
|
Min.turning Radius |
mm |
5340 |
|
|
Travel speed(with load/without load) |
km/h |
22/30 |
|
|
Front overhang |
mm |
920 |
|
|
Rear overhang |
mm |
960 |
|
|
Performance |
Max.lifting speed(with load/without load) |
mm/s |
240/300 |
|
Traction |
KN |
130 |
|
|
Gradeability(with load/without load) |
% |
20/22 |
|
|
Engine |
Manufacture |
WeiChai Engine |
|
|
Model |
WP6G175E22 |
||
|
Rated Output |
(Kw) |
129 |
|
|
Optional |
cummins |
||
|
6BTAA5.9-C190-II |
|||
|
Rated Output |
(Kw) |
142 |
|
|
Cylinder No |
6 |
||
|
Others |
Transmission gears(Front/rear) |
2/1 |
|
With technological innovation, our product configuration and parameters will continue to change without notice.
If there is any doubt, the specific confirmation of our international trade sales shall prevail.
