LTMG Machinery Group Co., Ltd. is one of the most reliable manufacturers and suppliers of 25 ton diesel operated forklift in China. Please feel free to buy high quality 25 ton diesel operated forklift for sale here from our factory. Good service and reasonable price are available.
The 25-ton diesel-operated forklift, equipped with a Weichai Engine and the optional Cummins, ensures strong power, energy conservation, and environmental protection.
- The steering system of this outdoor forklift features the adoption of a transverse oil cylinder type steering bridge, providing full-hydraulic steering that is flexible, light, and reliable.
- With imported technology, the transmission and torque converter deliver reliable performance, convenient maintenance, smooth transmission, and easy operation.
- The braking system utilizes mature products from professional manufacturers, incorporating disc brakes for faster heat dissipation, a light and simple structure, and easy adjustability. It particularly excels in thermostability performance under heavy loads, ensuring stable braking effects.
- The explosion-proof safety valve for the pipeline prevents sudden bursts, ensuring the system's safety and reliability. The control system includes a pilot valve control device to enhance work efficiency and reduce drivers' labor intensity.
- This big diesel forklift's frame structure showcases exquisite workmanship and a firm box-type frame, improving the transverse and longitudinal stability of the vehicle. The vehicle undergoes 3D finite element analysis, ensuring a superior structure and reliable quality. The main welding parts undergo nondestructive testing, effectively coordinating with the reinforced structure, bridge, and box.
- Featuring a standard hydraulic fork positioner, the fork provides easy operation and reduces drivers' labor intensity. The mast of the heavy-duty diesel forklift is a box-type internal-external mast with special all-round roller bearings, enhancing lifting performance.
- The cab of the 25-ton diesel-operated forklift combines a sleek and stylish design with a wide field of view. It features new composite decorative materials and comes equipped with air conditioning, ensuring a comfortable and cool environment even in hot working sites.
advantage
Technical Specification
| Model | FD250 | ||
| Features | Rated Load | Kg | 25000 |
| Load Center | mm | 1220 | |
| Wheelbase | mm | 4400 | |
| Weight | Weight | kg | 33500 |
| Chassis | Tire Specs: Front | 14.00-24 | |
| Tire Specs: Rear | 14.00-24 | ||
| Tires Qty, front/rear(X-dreve wheels) | 4/2 | ||
| Wheel tread: Front | mm | 2220 | |
| Wheel tread: Rear | mm | 2300 | |
| Dimensions | Mast/carriage tilt angle(front/rear) | Degree(°) | 6/12 |
| Mast height(fork lowering) | mm | 3970 | |
| Mast lifting height | mm | 4000 | |
| Max. height | mm | 5940 | |
| height to head guard(height to cab) | mm | 3440 | |
| Overall height(with forks) | mm | 8950 | |
| Fork front vertical surface to the rear end of the vehicle | mm | 6550 | |
| Overall width | mm | 3060 | |
| Fork dimension | mm | 2400*300*100 | |
| Fork carriage width | mm | 2800 | |
| Mast min ground(with load) | mm | 350 | |
| Wheelbase center min ground(with load) | mm | 420 | |
| Min. turning Radius | mm | 6160 | |
| Travel speed(with load/without load) | km/h | 25/30 | |
| Performance | lifting speed(with load/without load) | mm/s | 260/270 |
| tractionn | KN | 160 | |
| gradeability(with load/without load) | % | 20/22 | |
| Driving brake | Hydraulic clamp disvc | ||
| Engine | Engine brand | Dongfeng cummins | |
| Engine model | 6CTA8.3-C215 | ||
| Rated Output | 160(Kw) | ||
| Cylinder No | 6 | ||
| Others | Transmission gears(Front/rear) | 2/1 |
With technological innovation, our product configuration and parameters will continue to change without notice.
If there is any doubt, the specific confirmation of our international trade sales shall prevail.
certification
We take great pride in delivering top-quality and dependable products to our esteemed customers. We demonstrate our commitment to excellence through an extensive array of certifications, such as ISO, CE, EPA, COC, COR, SABER, and CO, solidifying our position as a trusted and respected leader in the industry. LTMG will continue to maintain the highest standards of quality to be a reliable partner for customers.
optional attachment
FAQ
Q: Would you offer a discount for a large order?
Q: In which field are your products applied?
Q: Do you accept custom designs in color?
Q: How can equipment issues during usage be resolved?
Q: What main software do you use in your product drawings?
