LTMG Machinery Group Co., Ltd. is one of the most reliable manufacturers and suppliers of fb30 electric forklift manufacturer in China. Please feel free to buy high quality fb30 electric forklift manufacturer for sale here from our factory. Good service and reasonable price are available. Some of the product features listed involve optional configurations. Please confirm the specific configuration with our international sales team.
Products Description
Higher Lifting Capacity
Increased lifting capacity meets the demands of handling medium-to-heavy loads.
01
Enhanced Stability
An extended wheelbase provides smoother travel under full load, significantly improving safety.
02
Robust Load Support
A reinforced frame easily handles intensive, high-demand lifting tasks.
03
Versatile Application
Combines strong load capacity with stability, adapting to a broader range of warehouse and handling scenarios.
04
Product Specifications
| Power Type | Electric | |
| Operation Type | Seated | |
| Rated Capacity | kg | 3000 |
| Load Center | mm | 500 |
| Front Overhang | mm | 467 |
| Wheel Base | mm | 1650 |
| Overall Weight | kg | 4300 |
| Axle Load, Laden (Front/Rear) | kg | 6600/700 |
| Axle Load, Unladen (Front/Rear) | kg | 1880/2420 |
| Tire Type | Solid | |
| Front Tyres | 28x9-15 | |
| Rear Tyres | 6.50-10 | |
| Wheel Number (Front/Rear) | 2×/2 | |
| Wheel Tread (Front) | mm | 1002 |
| Wheel Tread (Rear) | mm | 982 |
| Mast Tilt Angle (F/R) | ° | 6/12 |
| Mast Lowered Height | mm | 2065 |
| Free Lift Height | mm | 160 |
| Lift Height | mm | 3000 |
| Mast Extended Height | mm | 4255 |
| Overhead Guard Height | mm | 2115 |
| Seat Height | mm | 1150 |
| Towing Coupling Height | mm | 480 |
| Total Length without Fork | mm | 2650 |
| Overall Length (with Forks) | mm | 3720 |
| Overall Width | mm | 1240 |
| Fork Size | mm | 45x120x1220 |
| Fork Carriage Class | DIN 15173, Class A | |
| Fork Carriage Width | mm | 1100 |
| Ground Clearance, Laden | mm | 120 |
| Wheelbase Center Min. Ground | mm | 140 |
| Min. Right Angle Stacking Aisle Width (Pallet 1000x1200 Crossways) | mm | 4085 |
| Min. Right Angle Stacking Aisle Width (Pallet 800x1200 Lengthways) | mm | 4285 |
| Turning Radius | mm | 2250 |
| Min. Distance, Turning Center Line to Body Center Line | mm | 764 |
| Max. Travel Speed (Full/No load) | km/h | 12.5/14 |
| Max. Lifting Speed (Full/No load) | mm/s | 300/380 |
| Lowering Speed (Full/No load) | mm/s | 420/390 |
| Max. Gradeability (Full/No load) | % | 15/20 |
| Service Brake | Hydraulic | |
| Parking Brake | Mechanical | |
| Max. Drawbar Pull (5min) | kN | 12.5 |
| Drive Motor Rating (S2 60min) | kW | 15.2 |
| Lift Motor Rating (S3 15%) | kW | 24.2 |
| Battery | V/Ah | 80/210 |
| Attachment Relief Valve Pressure | MPa | 18 |
customer feedback
our company
LTMG certifications
FAQ
Q: How to handle oil leakage in the forklift's hydraulic system?
A: Stop the machine immediately to check the oil leakage point. If the pipeline joint is loose, tighten the joint; if the sealing ring is aged or the pipeline is damaged, replace the corresponding parts; after repair, add hydraulic oil to the standard level, and confirm no leakage before operation.
Q: How about our delivery time?
A: Usually it will take 15 to 30 days after receiving your deposit. About standard products, we always have in stock and can deliver immediately. But customized products will take more time, depending on the requirements of your order.
Q: What payment terms can we accept?
A: Normally 30% deposit is required in advance, 70% balance shall be settled before shipment. And 100% irrevocable L/C at sight with the terms we agreed can also be accepted.
Q: Can We Provide OEM Service?
A: LTMG industrial can provide customized products according to customers' requirements, both OEM and ODM are acceptable.
