LTMG Machinery Group Co., Ltd. is one of the most reliable manufacturers and suppliers of 4.5ton electric forklift standard 3m lifting height in China. Please feel free to buy high quality 4.5ton electric forklift standard 3m lifting height for sale here from our factory. Good service and reasonable price are available.
Products Description
4.5-ton electric forklift standard 3m lifting height
- Corresponding low-voltage DC charger provided based on lead-acid battery power, equipped with the China national standard charging gun; optional converters available for various charging specifications.
- Energy-saving design with load-sensing steering and AC control renewable energy tech, extending battery working time by 15%; AC motor offers higher speed, stronger power, faster response, and lower maintenance without carbon brushes or diverters.
- Optional imported INMOTION electronic control with the latest ACS series AC motor driver for smooth current drive, ideal for traction, lifting, and vehicle control.
- Cost-effective, high-rate discharge lead-acid battery with good temperature performance and no flammability; maintenance-free wet disc brake system and integrated cast drive axle ensure durability, low deformation, waterproof/dustproof design, and low maintenance cost.
How to find an affordable and useful electric forklift
Products parameter of 4.5 ton electric forklift
| Model | FB45 | |
| Rated Capacity | kg | 4500 |
| Load Center Distance | mm | 500 |
| Power Type | Battery | |
| Wheel Base | mm | 1800 |
| Wheel Number(Front/Rear) | 2×/2 | |
| Front Tread | mm | 1160 |
| Rear Tread | mm | 970 |
| tyre(Front) | 250-15-12PR | |
| Tyre(Rear) | 18X7-8-16PR | |
| Front Overhang | mm | 520 |
| Mast Tilting Angle, Front/Rear | 6/12 | |
| Height With Mast Retraction | mm | 2150 |
| Free Lifting Height | mm | 150 |
| Max.Lifting Height | mm | 3000 |
| Max.Height After Lifting | mm | 4272 |
| Overall Guard Height | mm | 2092 |
| Fork Size: Length X Width X Thickness | mm | 1070×125×50 |
| Overall Length(Fork Excluded) | mm | 2690 |
| Overall Width | mm | 1420 |
| Turning Radjus | mm | 2550 |
| Ground Clearance Of Mast | mm | 130 |
| Ground Clearance Of Wheel Base Center(Loaded) | mm | 130 |
| Right Angle Stacking Aisle Width (Pallet 1000×1000Mm) Clearance 200Mm | mm | 4250 |
| Right Angle Stacking Aisle Width (Pallet 1200×1200Mm) Clearance 200Mm | mm | 4450 |
| Lateral Fork Adjustment Max./Min | mm | 1300/250 |
| Travelling Speed (Loaded/Unloaded) | km/h | 12/13 |
| Lifting Speed (Loaded/Unloaded) | mm/s | 250/350 |
| Lowering Speed | mm/s | <600 |
| Gradeability (Loaded) | % | 14 |
| Self Weight | Kg | 5440 |
| Battery Voltage /Capacity | V/Ah | 80/560 |
| Battery Weight | Kg | 1240 |
| Driving Motor Power-60 Minutes | Kw | 16.6 |
| Lifting Motor Power(S315%) | Kw | 13.5 |
| Driving Motor Control Mode | Full AC | |
| Lifting Motor Control Mode | Full AC | |
| Service Brake/Parking Brake | Hydraulic /Mechanical | |
| Hydraulic System Working Pressure | Mpa | 20.0 |
With technological innovation, our product configuration and parameters will continue to change without notice.
If there is any doubt, the specific confirmation of our international trade sales shall prevail
4.5-ton electric forklift standard 3m lifting height
Company Introduction
Shipping plan
certificate
In foreign trade, various export certificates play a crucial role in ensuring the smooth crossing of national borders, compliance with import country regulations, and safeguarding the rights and interests of both parties in transactions.
Customer Feedback
FAQ
Q: How long does a fully charged electric forklift battery typically last? Can it operate through multiple work shifts without needing a recharge?
Q: Maintenance Needs Are electric forklifts generally lower maintenance compared to their internal combustion counterparts? What routine checks are necessary?
